| Parameter | Value |
|---|---|
| Model | EVH9AX-800G1BC |
| Brand | ALQ |
| Rated Current | 800 A |
| Max. Switching Voltage | 1500 V DC |
| Rated Load Voltage (Ue) | 12 - 1500 V DC |
| Power Contact Arrangement | SPST-NO-DM (Single Pole Single Throw, Normally Open, Dual Make) |
| Auxiliary Contact | SPST-NO / SPST-NC / None (optional) |
| Coil Voltage (Us) | 12 V DC / 24 V DC / 48 V DC (optional) |
| Coil Type | Single coil |
| Contact Resistance (initial) | Typical 1 mOhm |
| Dimensions (L x W x H) | 168.0 x 86.0 x 97.4 mm |
| Mounting Type | Modular |
| Origin | Jiangsu, China |
| Warranty | 1 year |
| Electrical Life | [To verify: DC450V - 10,000 operations; DC750V - 1,000 operations] |
Engineered for high-voltage DC systems up to 1500 V DC, the EVH9AX-800G1BC ensures stable performance under frequent on-load switching -- ideal for electric vehicles, DC fast charging, and energy storage applications.
Unique dual-make contact design prevents contact welding during inrush current events -- critical for battery packs, chargers, and PCS systems where capacitive surges are common.
Epoxy-sealed body provides superior protection against dust, moisture, and vibration -- achieving [IP rating to verify] level protection without additional housing, suitable for harsh industrial environments.
Available with coil voltages of 12 V DC, 24 V DC, or 48 V DC, making integration easy across various low-voltage control systems in EVs, charging piles, and industrial equipment.
SPST-NO-DM power contact with optional auxiliary contact (NO / NC / None). Rated current up to 800 A covers demanding high-power EV and energy storage applications. Modular mounting for easy installation and replacement.
CE, ISO9001:2015, TUV, CCC certified. Quality management system conforms to GB/T19001-2016 / ISO9001:2015.
Industrial Vehicles Electric forklifts, electric pallet trucks, electric aerial work platforms, intelligent logistics systems, automated guided vehicles (AGV), cold chain logistics equipment, industrial robots, electric tools, electric golf carts, etc. |
DC Charging Equipment Chargers, small DC charging piles, monoblock DC charging piles, split-type DC charging piles (group charging), ultra-fast DC charging piles, integrated DC charging piles for heavy-duty trucks, etc. |
Energy Storage System Large-scale energy storage (generation-side, grid-side), medium-scale energy storage (industrial & commercial), small-scale energy storage (residential), etc. |
Frequency Conversion Equipment High-voltage frequency converters, power conversion systems (PCS), and industrial rectifier power supplies, etc. |
A: The EVH9AX-800G1BC supports a maximum switching voltage of 1500 V DC, making it suitable for high-voltage electric vehicle and energy storage applications.
A: The contactor is available with 12 V DC, 24 V DC, or 48 V DC coil voltages. Select the option that matches your control system when ordering.
A: Yes. The EVH9AX-800G1BC is designed for energy storage systems (ESS), including generation-side, grid-side, industrial & commercial, and residential applications. Its high current rating (800 A) and 1500 V DC voltage make it ideal for large-scale battery banks and PCS systems.
A: The power contact uses an SPST-NO-DM (Single Pole Single Throw, Normally Open, Dual Make) configuration. An optional auxiliary contact is available in SPST-NO, SPST-NC, or none.
A: The EVH9AX-800G1BC is rated for 800 A -- significantly higher than standard models (e.g., 50 A, 150 A, 300 A). It is specifically engineered for high-power applications such as ultra-fast DC charging piles and large-scale energy storage, where lower-current contactors cannot safely operate.
A: Submit your required specifications (current, coil voltage, auxiliary contact type) through the inquiry form or contact us via WhatsApp. Our engineers will respond within 24 hours. Sample lead time is [to verify with factory].
