Type
|
NM8NDC-250S
|
|
Demensions(LxWxH)
|
40/70/105/140×157×88.7mm
|
|
Rated Current(Optional)
|
200A
|
|
Max. Switching Voltage
|
1000Vdc
|
|
Power Contact Arrangement
|
DPST-NO-DM
|
|
Auxiliary Contact Arrangement(Optional)
|
SPST-NO/SPST-NC / None
|
|
Coil Voltage Rating(Optional)
|
12Vdc-24Vdc
|
|
Rated Coil Power(Optional)
|
4.0W
|
|
Coil Characteristics
|
Single coil +PWM
|
 |
 |
Industrial VehiclesTypical applications in the industrial vehicle industry:electric for klifts,electric pallet trucks,electric aerial work platforms,intelligent logistics systems, automated guided vehicles(AGV),cold chain logistics equipment, industrial robots,electrictools,electric golf carts,etc. |
DC Charging EquipmentTypical applications in the DC charging equipment industry:charger,small DC charging pile,monoblock |
 |
 |
Energy Storage SystemTypical applications of energy storage systems: large-scale energy storage(generation-side, grid-side), medium-scale energy storage (industrial & commercial),small-scale energy storage (residential),etc.
|
Frequency Conversion EquipmentTypic alapplications of frequency conversion equipment: high-voltage frequency converters, power conversion system(PCS),and industrial rectifier power supplies,etc.
|
