Modle |
SUN-9K-G02P1-EU-AM2 |
SUN-10K-G02P1-EU-AM2 |
SUN-10.5K-G02P1-EU-AM2 |
|
|
Max. PV Input Power(kW) |
13.5 |
15 |
15.8 |
||
Max. PV Input Voltage(V) |
550 |
||||
Start-up Voltage(V) |
80 |
||||
MPPT voltage range(V) |
70-500 |
||||
Rated PV Input voltage(V) |
360 |
||||
Max. Input Short Circuit Current (A) |
39+39 |
||||
Max. Operating PV Input Current(A) |
26+26 |
||||
No. of MPP Trackers/No. of Strings per MPP Tracker |
2/2+2 |
||||
AC Output Side |
|||||
Rated AC Output Active Power(kW) |
9 |
10 |
11 |
||
Max. AC Output Apparent Power(kVA) |
9.9 |
11 |
11.55 |
||
Rated AC output current (A) |
41/39.2 |
45.5/42.5 |
47.8/45.7 |
||
Max. AC Output Current(A) |
45/43.1 |
50/47.9 |
52.5/50.3 |
||
Rated output voltage/range (V) |
220/230 0.85Un-1.1Un |
||||
Grid Connection Form |
L/N/PE |
||||
Rated Output Grid Frequency/range(Hz) |
50/45-55, 60/55-65 |
||||
Power Factor Adjustment Range |
0.8 leading to 0.8lagging |
||||
Total Current Harmonic Distortion THDi |
<3% |
||||
DC Injection Current |
<0.5%ln |
||||
Efficiency |
|||||
Max. Efficiency |
97.70% |
||||
Euro Efficiency |
97.20% |
||||
MPPT Efficiency |
>99% |
||||
Equipment Protection |
|||||
DC Polarity Reverse Connection Protection |
yes |
||||
AC Output Overcurrent Protection |
yes |
||||
AC Output Overvoltage Protection |
yes |
||||
AC Output Short Circuit Protection |
yes |
||||
Thermal Protection |
yes |
||||
DC Terminal Insulation Impedance Monitoring |
yes |
||||
yes |
|||||
DC Component Monitoring |
yes |
||||
Ground Fault Current Monitoring |
yes |
||||
Arc Fault Circuit Interrupter (AFCI) |
Optional |
||||
Power Network Monitoring |
yse |
||||
Island Protection Monitoring |
yse |
||||
Earth Fault Detection |
yse |
||||
Overvoltage Load Drop Protection |
yse |
||||
Residual Current (RCD) Detection |
yse |
||||
Surge Protection Level |
TYPE II(DC),TYPE II(AC) |
||||
Interface |
|||||
Communication Interface |
RS485/RS232 |
||||
Monitor Mode |
GPRS/WIFI/Bluetooth/4G/LAN(optional) |
||||
General Data |
|||||
Operating Temperature Range (°C) |
(-25 to +60℃, >45℃ Derating) |
||||
Permissible Ambient Humidity |
0~100% |
||||
