Modle |
NDZ3X-350 |
|
|
Rated current |
350A |
||
Agreed free-air heating current Ith |
500A |
||
Rated voltage |
DC 750V 350A 800 times |
||
Insulation voltage:Ui |
DC 1000V |
||
Number of poles |
single pole |
||
Circuit type |
direct-current |
||
Mechanical life |
One million times, frequency 1200, |
||
Electrical life (DC-1,360 times / hour, 1s |
DC 750V 350A 800 times |
||
Maximum cut-off current |
DC 320V 2000A 1 times |
||
Short-circuit withstand current |
3750A 30ms |
||
Insulation resistance |
≥100MΩ, DC500V |
||
Withstand voltage |
AC 3500V 60s |
||
Rated control voltage, Uc |
Rated voltage: DC 12V~24V |
||
Maximum starting current (20℃) |
≤3.5A |
||
Maintain power consumption (20℃, rated |
≤3.6W /3.6VA |
||
Suction / release time (rated voltage) |
≤35ms /20ms |
||
Secondary contact type |
No auxiliary, 1NO, 1NC, 1NC + 1NO |
||
Auxiliary contact current |
2A /DC 30V ,3A/AC125V |
||
Auxiliary contact turn-on minimum capacity |
8V 100mA |
||
